TMC2209 StepStick Stepper Motor Driver, 5PCS TMC2209 Mute Drive with Heat Sink For Reprap 3D Printer

TMC2209 StepStick Stepper Motor Driver, 5PCS TMC2209 Mute Drive with Heat Sink For Reprap 3D Printer

$ 25.99 USD
$ 25.99 USD $ 25.99 USD
Sale Sold out
Shipping From
Option

 The TMC2209 is an ultra-silent motor driver for two phase stepper motors.It helps the noiseless operation, maximum efficiency and best motor torque.Most advanced stepper motor driver family upgrades design to noiseless and most precise operation for cost-effective and highly competitive solutions.

Special Features:
- Ultra quiet than Tmc2208;
- Large Aluminum heat sink,good heat dissipation.
- Support sensorless-homing function.
- Support uart mode by set jumper caps instead of welding on mks gen_l V2.0, skr1.3/1.4,mks sgen_l;

Open Source File/Instructions: https://github.com/makerbase-mks/MKS-TMC2209
View full details
